Mahsulot tafsilotlari
Mission40 burg'ulash sanoatining foydali qazilmalarini qidirish, karer, tog'-kon, suv qudug'i va geotexnika sohalariga xizmat ko'rsatadigan yuqori sifatli pnevmatik bolg'a.
Vizyonimiz dillerlarning birinchi tanlovi bo'lish, burg'ulash ishlarini yanada muvaffaqiyatli olib borishdir.
Mission40 dth bolg'alarining texnik parametrlari
Bit Shank | MISSIYA 40 | |
Teshik diapazoni | P110-130mm | |
Ulanish ipi | API 2 3/8" Reg | |
Ish bosimi | 10-25Bar / 1-2.5Mpa | |
Havo iste'moli (m3/min) | 14Bar | 7 |
24Bar | 14.2 | |
Uzunlik | 1005 mm | |
Og'irligi | 40 kg | |
Tezlik tavsiya etiladi | 30-70rpm | |
Pull Force tavsiya etiladi | 7,5 KN | |
Mission40 DTH bitlarining texnik parametrlari
Diametri | O'lchov tugmalari | Old tugmalar | Og'irligi (KG) | Qism raqami | ||||
mm | dyuym | Yassi yuz | Qavariq yuz | Botiq yuz | Yuz turi | |||
115 | 4 1/2 | Φ14*7 | Φ14*2 | Φ14*4 | / | Qavariq yuz | 8.1 | LR-MISSION40-115CV-1 |
115 | 4 1/2 | Φ16*7 | Φ14*2 | Φ14*4 | / | Qavariq yuz | 8.1 | LR-MISSION40-115CV-2 |
115 | 4 1/2 | Φ14*8 | Φ14*2 | Φ14*4 | / | Qavariq yuz | 8.1 | LR-MISSION40-115CV-3 |
125 | 4 15/16 | Φ14*8 | Φ13*3 | Φ14*4 | / | Qavariq yuz | 8.7 | LR-MISSION40-125CV |
127 | 5 | Φ14*8 | Φ13*7 | / | / | Yassi yuz | 8.8 | LR-MISSION40-127FF |
130 | 5 1/8 | Φ14*8 | Φ14*7 | / | / | Yassi yuz | 9.0 | LR-MISSION40-130FF |
